PANDUIT DNF18-250M-C Male Disc,Nickel,Copper,Nylon,PK100 39AY61

Specifications

Male Disconnect, Contact Finish Nickel, Contact Material Copper, Disconnect Style Tab, Insulation Color Red, Insulation Coverage Partial Coverage, Insulation Material Nylon, Maximum Operating Temperature 221 Degrees F, Minimum Wire Size 22 AWG, Maximum Wire Size 18 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Tab, Termination Style Crimp, UL 94 Flammability Rating HB, V-2, RoHS Compliant Yes, Seam Style Sleeved Barrel This disconnect lowers installation cost with its ability to be inserted and removed from the female disconnect without the aid of tools. Male disconnect can pair with all female disconnects that have the corresponding tab size.

Related Items

Hilitchi 100pcs 12-10 Gauge Butt Insulated Splice Terminals Electrical Wire C…

Panduit PV18 8F CY Vinyl Insulated Spade Terminals #8 Stud 100 PCS Bottle

Klein/Vaco C61210 Insulated Ring Terminals 22-18 AWG, 3-100 Packs 300 Total G40

100pcs Non Insulated Butt Connectors Kit Butt Splice Connectors Uninsulated C…

PANDUIT PAN-TERM TERMINALS BSN10-L, BOX OF 41, BUTT SPLICE, FOR USE ON 10-12AWG

C20208 PECO LOT OF 100 FULLY INSULATED NYLON MALE QUICK DISCONNECT, LOT OF 100,

Panduit® – P18-6F-C Fork Terminal Non-Insulated 22 – 16 AWG #6 Stud Size Qty 300

VELVAC 37187 Male Disc,Tin,Copper,Nyl/Polyolefin,PK10 21DG79
